Delivering Well-Approved Services to Protect Life & Property

WHAT IS FIRESTOPPING?

Firestopping solutions are used, in combination with a various range of materials and components, to seal joints, openings and penetrations in fire rated resistance walls or floor systems. Firestops are implemented to restore the fire resistance rating and maintain the fire resistance qualities of such passive fire protection systems, reducing the spread of fire and filling the penetrations with fire resistant methods and products. Unprotected openings in fire separations make your fire resistance wall obsolete in terms of fire resistance rating, and ultimately provide fire an unimpeded route to spread and damage your assets. Structures are built with fire rated resistance walls, barriers, partitions and floors which allows fire compartmentation of the building. However, joints between penetrations or entrances in passive fire protection systems can nullify the security they were implemented to make. RISE & SHINE fire stopping solutions are devised and built as vital parts to passive fire protection.



Fire rated wall, barrier, and floor opening types

Unprotected fire separations defuse the functionality and resistance rating of any passive fire protection system. What to look for:

  1.         Electrical through-penetrations

  2.         Mechanical through-penetrations

  3.         Structural through-penetrations

  4.         Unpenetrated openings (openings for future use for example)

  5.         Re-entries of existing firestops

  6.         Control or sway joints within fire-resistance rated wall or floor assemblies

  7.         Junctions between fire-resistance rated wall or floor assemblies

  8.       "Head-of-wall" (HOW) joints, where non-load bearing wall assemblies meet floor  assemblies

Fire stop systems

  •   Firestop block and plug – designed for retrofitted cables.

  •   Firestop foam – seal pipe and cable penetrations, from small to medium sized applications.

  •  Firestop cast-in and sleeve – specially designed for pipe penetrations through fire- rated floors.

  •  Firestop collars, wraps and bandages – protect all of your piping penetrations

  •  Firestop sealants & sprays – firestopping solutions for walls and joints between floors and walls.

  •  Firestop cable protection – cable protection to reduce flame damage.

  •  Firestop coatings systems, cushions and mortars – combustible and non-combustible pipe and insulation materials, to firestop penetration seals.
